Features:
- Hand wheel translation and quick opening structure.
- Internal steam cycle.
- High quality stainless steel material.
- With drying function.
- Microcomputer automatic control, arbitrary setting sterilization parameters.
- Safety interlocking device.
- Digital display and Touch buttons.
- Standard test interface.
- Self-expanding seal.
- With automatic protection function:over temperature protection; over pressure self discharge protection ;low water level protection; anti dry burning.
- With stainless steel bucket or basket.
- Buzzer reminder after sterilization, automatic stop.
- Automatic discharge of cold air, automatic steamexhaust after sterilization.
*Optional external printer
Specification:
| Model | TGL-35X | TGL-50X | TGL-75X | TGL-100X |
| Volume | 35L | 50L | 75L | 100L |
| Power | 3.5kW | 3.5kW | 4.5kW | 4.5kW |
| Voltage | AC220V、50HZ | |||
| Rated working pressure | 0.22MPa | |||
| Rated working temperature | 134℃ | |||
| Sterilization temperature setting range | 50℃~134℃ | |||
| Sterilization time setting range | 4~120 min | |||
| Drying time setting range | 0~240 min | |||
| Chamber volume | Φ350*400 | Φ350*525 | Φ400*625 | Φ450*650 |
| Bucket dimension | Φ330*320 | Φ330*460 | Φ380*560 | Φ430*540 |
| Basket dimension | Φ320*350 | Φ320*240*2 | Φ360*280*2 | Φ410*300*2 |
| Outer dimension | 698*498*940 | 698*498*1110 | 770*570*1185 | 788*588*1255 |
| Packing size (L*W*H) | 790*610*1130 | 800*600*1230 | 840*610*1310 | 870*650*1380 |
| Gross/net weight | 125/110KG | 130/112KG | 145/114KG | 156/129KG |
