Features:
- Horizontal square inner chamber + jacket structure,safety, heat preservation, and drying function.
- Disc type embedded gear + Electric lock door structure,safety and reliable.
- The door seal is pneumatic, single or double door(double door interlock).
- Equipped with standard equipment verification interface.
- Pipeline system for the optimal design, SUS304 pipeline, clamp structure, quick assembly.
- Control system: HMI man-machine interface,touch screen+PLC.
- F0 value and temperature time double guarantee sterilization effect, with perfect sterilization records.
- With program selection, parameter setting, equipment operation, report processing and traceability Functions.
- Three levels of authority management.
- Multiple safety protection(over-temperature, over-pressure protect).
- Sterilization process: fabric, equipment, liquid, BD, pressure testing, custom defined multiple procedures.
Specification:
| Design pressure | -0.1~0.3Mpa | Design temperature | 144℃ |
| Working pressure | 0.245Mpa | Working Temperature | 105~138℃ |
| Vacuum | -0.086Mpa | Temperature Equilibrium | <+2.0℃ |
| Water Pressure | 0.1~0.2Mpa | Compressed air pressure | 0.4~0.7Mpa |
| Steam Pressure | 0.3~0.7Mpa | Power voltage | Three-phase five-wire
AC380V 50Hz |
