Features:
- The shell of the product is made of cold-rolled steel plate, and the surface is electrostatically sprayed.
- The studio is made of high-quality 304 mirror-finished stainless steel, with four-corner arc transitions, double inner tanks, and a beautiful appearance.
- Equipped with 304 stainless steel handle, adjustable and more airtight.
- Using intelligent PID temperature control instrument, it has functions such as timing, over-temperature alarm indication, temperature deviation correction, and temperature control self-tuning.
- The fully enclosed stainless steel heating tube is combined with the air jacket heating method, and the high-temperature fan circulates to make the temperature more uniform.
- The sealing strip is made of aviation sealing material, which can withstand high temperature up to 1000℃.
- Air supply mode: fan forced circulation.
- Thickened heat preservation, with a heat insulation layer inside.
- It can be equipped with LCD instrument, program control instrument, printer, 485 interface, U disk storage, SMS alarm and other functions.
Specification:
| Model | TW-50BE | TW-80BE | TW-150BE | TW-250BE | TW-350BE |
| Capacity | 50L | 80L | 150L | 250L | 350L |
| Power supply | 220V 50HZ | 380V 50HZ | |||
| Temperature control range | 50-500℃ | ||||
| Temperature resolution | 0.1℃ | ||||
| Temperature fluctuation | ±1℃ | ||||
| Power | 300W | 3000W | 4500W | 5500W | 6500W |
| Studio Size (D*W*H) mm | 330*350*350 | 400*400*500 | 500*500*600 | 500*650*750 | 1000*440*800 |
| Dimensions (D*W*H) mm | 510*650*750 | 575*700*880 | 640*800*1040 | 640*950*1190 | 1190*770*1280 |
| Package size (D*W*H) mm | 620*820*820 | 670*700*900 | 775*935*1180 | 775*1085*1330 | 1200*750*1130 |
| Net weight/gross weight KG | 58/68 | 80/94 | 102/121 | 135/156 | 160/190 |
