Features:
- Stretched shell and cover prevent leaking.
- Heating and stirring can be used simultaneously, uniform temperature, heating fast and safety.
- Heating power and stirring speed stepless adjustable, Max. temperature up to 380 degree, Max. speed up to 2000 r.p.m.
TH-4C model:
- Temperature setting accurately and the stirring speed is stepless adjustable.
- Large screen LCD display with backlight, real temperature and real speed display on the screen simultaneously.
- Two sensor outside PT100 sensor controls the liquid tempertature with high precise, inside K type sensor controls the hot plate temperature.
TH-II-4C model:
- Setting rotational speed precisely and the stirring speed is stepless adjustable. This instrument with the speed switch can start and stop stirring at any time.
- With the function of timing (0-9999min) that can set time in accordance with customers’ requirement. The instrument also with audible and visual alarm.
- Dual inside and outside sensors, the outside PT100 sensor can control precisely the temperature of heated liquid. The inside K sensor can control the temperature of hot plate.
- One key to shift inside and outside sensor, easy to operate and control precisely.
- Large screen LCD display can indicate temperature, rotational speed and timing at the same time.
Specification:
| Model | TH-4A | TH-4B | TH-4 | TH-4C | TH-II-4C | |
| Mode | Heating | Stirring | Heating + Stirring | Digital+ Heating + Stirring | ||
| Function | Max. Volume(ML) | no | 5000 | 5000 | 5000 | 5000 |
| Speed(r.p.m) | no | 200～2000 | ||||
| Working time | Continuous | |||||
| Minimum revolution ( R.P.M.) | no | 200 | 200 | 200 | 200 | |
| Max. temp（℃） | 380 | no | 380 | 350 | 350 | |
| Structure | Exterior | Iron plate welding, surface spraying | ||||
| Heating plate | Aluminum tensile | |||||
| Driving mode | no | Motor | ||||
| Motor power (W) | no | 20 | 20 | 20 | 20 | |
| Heating power(kW) | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | |
| Stir bar | no | PTFE | ||||
| Controller | Continuous operation | yes | ||||
| Setting mode | Scale | Digita | ||||
| Speed display mode | Scale | Digital | Digital | |||
| Timer | no | yes | ||||
| Operation function | no | yes | ||||
| Sensor | no | PT100 | PT100 | |||
| Specification | Exterior size (W*L*H)(mm) | 320*190*125 | ||||
| Packing size (W*L*H)(mm) | 390*240*230 | |||||
| Plate size（mm） | 190*190 | |||||
| Plate load | 10KG | |||||
| Power supply（50/60Hz）Current rating | 110V or 220V | |||||
| NW/GW (kg） | 5/6 | 5/6 | 5/6 | 5/6 | 5/6 | |
