Features:
- Horizontal forced air type, high space utilization and good temperature uniformity.
- 101: The fan heat dissipation structure makes the working temperature of the fan less than 50℃, so that the fan can run for along time.
- 202: Classical natural convection drying method.
- New anti-hot handle.
Specification:
| Model | T-101-0A/101-0AB | T-101-1A/101-1AB | T-101-2A/101-2AB | T-101-3A/101-3AB | |
| T-202-0A/202-0AB | T-202-1A/202-1AB | T-202-2A/202-2AB | T-202-3A/202-3AB | ||
| Cycle Mode | 101 means Forced convection; 202 means Natural convection | ||||
| Function | Temp. Range | RT+10-250℃ | |||
| Temp. Resolution Ratio | 0.1℃ | ||||
| Temp. Motion | ±1℃ | ||||
| Temp. Uniformity | ±2.5% | ||||
| Structure | Inner Chamber | B model: High quality stainless steel; | |||
| without B model:High strength galvanized sheet | |||||
| Outer Shell | Cold rolling steel electrostatic spraying exterior | ||||
| Insulation layer | High quality rock wool board (with CE) | ||||
| Heater | T-101 model with Stainless steel electric heating tube; | ||||
| T-202 model with Nickel chromium alloy heating wire | |||||
| Power rating | 1.2kW | 1.6kW | 2.3kW | 3.0kW | |
| Exhaust hole | φ35 mm top(with function of test hole) | ||||
| Controller | Temp. control mode | Two temperature section PID intelligent | |||
| Temp. setting mode | Touch button setting | ||||
| Temp. display mode | LED Digital display | ||||
| Timer | 0-9999min(with timing wait function) | ||||
| Operation function | Fixed temperature operation, timing function,auto stop. | ||||
| Additional function | Sensor deviation correction, temperature overshoot self-tuning, internal parameter locking, power-off parameter memory | ||||
| Sensor | PT100 | ||||
| Safety device | Over temperature sound-light alarm | ||||
| Specification | Inner Chamber size(W*L*H)(mm) | 350*350*350 | 450*350*450 | 550*450*550 | 600*500*750 |
| Exterior size (W*L*H)(mm) | 652*472*587 | 752*472*687 | 852*572*786 | 902*622*986 | |
| Packing size (W*L*H)(mm) | 755*615*735 | 855*615*835 | 955*715*935 | 1005*765*1135 | |
| Volume | 43L | 71L | 136L | 225L | |
| Shelf number | 9 | 13 | 17 | 25 | |
| Load per rack | 15kg | ||||
| Shelf space | 25mm | ||||
| (50/60HZ)Current rating | AC220V/5.5A | AC220V/7.3A | AC220V/9.1A | AC220V/13.6A | |
| NW/GW (kg） | 33/37 | 45/50 | 62/68 | 77/96 | |
| Accessory | Shelf | 2 | |||
| Shelf frame | 4 | ||||
| Optional accessories | Shelf | ||||
