Features:
- Bolt structure.
- High quality stainless steel material.
- Microcomputer automatic control, arbitrary set of sterilization parameters.
- Safety interlocking device.
- Digital display and touch buttons.
- Standard test interface.
- Self-expanding seal.
- The container with automatic protection function:over temperature protection; over pressure protection self discharge; low water level protection, anti dry burning.
- With stainless steel bucket or basket.
- Buzzer reminder after sterilization, automatic stop.
- Automatic cooling air, sterilization end automatic exhaust steam.
*Optional external printer
Specification:
| Model | TGLS-35B | TGLS-50B | TGLS-75B | TGLS-100B | TGLS-120B | TGLS-150B |
| Volume | 35L | 50L | 75L | 100L | 120L | 150L |
| Power | 2.5kW | 3.5kW | 4.5kW | 4.5kW | 4.5kW | 6kW |
| Voltage | AC220V、50HZ | |||||
| Rated working pressure | 0.22MPa | |||||
| Rated working temperature | 134℃ | |||||
| Sterilization temperature setting range | 50℃~134℃ | |||||
| Sterilization time setting range | 4~120 min | |||||
| Drying time setting range | 0~240 min | |||||
| Chamber volume | Φ300*500 | Φ350*525 | Φ400*625 | Φ450*650 | Φ450*760 | Φ500*780 |
| Bucket dimension | Φ280*400 | Φ330*460 | Φ380*560 | Φ420*540 | Φ420*660 | Φ470*720 |
| Basket dimension | Φ320*240*2 | Φ360*280*2 | Φ410*300*2 | Φ410*350*2 | Φ460*350*2 | |
| Outer dimension | 400*400*860 | 480*480*960 | 522*567*1020 | 555*555*1080 | 555*599*1200 | 605*649*1210 |
| Packing size (L*W*H) | 550*500*1030 | 580*630*1100 | 630*680*1190 | 690*650*1230 | 690*650*1330 | 750*700*1370 |
| Gross/net weight | 58/41KG | 75/53KG | 82/61KG | 103/78KG | 108/82KG | 116/90KG |
