Features:
- This machine can be equipped with a variety of angle rotors and horizontal rotors and adapters, suitable for centrifugation of 0.2ml-750ml test tubes/centrifugal bottles and working plates. It is an ideal choice for molecular biology, clinical medicine, inspection and quarantine and other fields.
- Compact structure design, small footprint, saving laboratory space.
- Double lock head, double hydraulic rod design, self-priming silent door lock, safe and reliable.
- The intelligent temperature control system adopts the international first-line brand, and the temperature control is fast and accurate.
- RFID rotor intelligent identification technology can instantly identify the rotor specification, maximum speed, maximum centrifugal force, production date, usage and other information without running it, which is convenient for users to manage the rotor. The number of rotors is not limited, and the system can quickly identify even non-standard customized rotors.
- Using a three-axis gyroscope to monitor the vibration state of the main shaft in real time during operation, it can accurately detect abnormal vibration caused by liquid leakage or unbalanced loading, that is, it will actively stop the machine immediately and activate an unbalanced alarm. Compared with the traditional switch detection, it has better reliability and higher accuracy.
- Adopt maintenance-free variable frequency motor drive, LCD touch screen, easy to operate.
- All steel casing, 316 stainless steel inner cavity, three-layer protective steel sleeve.
- Can store 1000 program groups, and can be password-locked to prevent accidental modification.
- It can store 1000 usage records, which is convenient for users to trace records.
- In addition to locking the host computer with a password, you can also lock the parameters of the program group with a password alone, and the two functions can be used independently without restricting each other.
- It can be set up to 5 stages of step centrifugation to meet the requirements of diversified experiments.
- With curve display function, the operating parameters are intuitively displayed on the screen in the form of curves to monitor the change process and stability of each parameter.
- Countup/countdown optional.
- 40 speed-up and down-speed gears are adjustable. When the speed drops to 500rpm~0, the curve is used to slow down to prevent the sample from reverberating and effectively improve the sample recovery rate.
- Speed/centrifugal force automatic conversion and display on the same screen.
- The volume of the prompt sound can be adjusted.
- Remote switch on and off (optional).
- Standard ECO energy-saving module.
Specification:
| Maximum speed | 21000 r/min |
| Max. RCF | 30810*g |
| Maximum capacity | 4*750ml (4000rpm) |
| Speed accuracy | ±10 r/min |
| Temperature setting range | -20℃ ～40℃ |
| Timing range | 1min~99H59 min |
| Noise | ≤56dB (A) |
| Power supply | AC 220V 50HZ 15A |
| Power | 1.5KW |
| Dimensions | 600*680*420(L*W*H)mm |
| Weight | 108kg |
