Features:
- Hand wheel translation and quick opening structure.
- High quality stainless steel material.
- Microcomputer automatic control, arbitrary setting sterilization .parameters.
- Safety interlocking device.
- Digital display and Touch buttons.
- Standard test interface.
- Self-expanding seal.
- With automatic protection function:over temperature protection; over pressure self discharge protection ;low water level protection; anti dry burmning.
- With stainless steel bucket or basket.
- Buzzer reminder after sterilization, automatic stop.
- Automatic discharge of cold air ,automatic steam exhaust after sterilization.
*Optional external printer
Specification:
| Model | TGL-35B | TGL-50B | TGL-75B | TGL-100B |
| Volume | 35L | 50L | 75L | 100L |
| Power | 3.5kW | 3.5kW | 4.5kW | 4.5kW |
| Voltage | AC220V、50HZ | |||
| Rated working pressure | 0.22MPa | |||
| Rated working temperature | 134℃ | |||
| Sterilization temperature setting range | 50℃~134℃ | |||
| Sterilization time setting range | 4~120 min | |||
| Chamber volume | Φ350*400 | Φ350*525 | Φ400*625 | Φ450*650 |
| Bucket dimension | Φ330*320 | Φ330*480 | Φ380*540 | Φ430*550 |
| Basket dimension | Φ320*350 | Φ320*240*2 | Φ360*280*2 | Φ410*300*2 |
| Outer dimension | 480*480*1020 | 480*480*1050 | 525*525*1200 | 555*555*1250 |
| Packing size (L*W*H) | 580*630*1130 | 580*630*1230 | 630*680*1290 | 690*650*1410 |
| Gross/net weight | 79/58KG | 106/80KG | 120/90KG | 133/106KG |
