Features:
- The unique design of the furnace door makes the opening operation safe and easy, and ensures that the high-temperature hot gas in the furnace does not leak.
- Microcomputer PID controller, easy to operate, accurate temperature control, reliable and safe.
- Corrosion-resistant and lightweight furnace to ensure durability.
- Excellent door sealing minimizes heat loss and increases the uniformity of temperature in the furnace.
- TSZH series atmosphere protection resistance furnace are equipped with air inlet and outlet devices on both sides of the front and back, which can be filled with inert gas, so that the heating device will not be oxidized and decarbonized.
Specification:
| Model | Atmosphere Protection Resistance Furnace TSZH Series | |||||||
| TSZH-1002 | TSZH-1004 | TSZH-1008 | TSZH-1012 | TSZH-1202 | TSZH-1205 | TSZH-1210 | TSZH-1212 | |
| Rated power | 2.5KW | 4KW | 8KW | 12KW | 2.5KW | 5KW | 10KW | 12KW |
| Voltage | 220V | 380V | 220V | 380V | ||||
| Heating element | Resistance wire | Resistance wire | ||||||
| Temperature measuring element | K-type thermocouple | K-type thermocouple | ||||||
| Liner size (mm) (Width*depth*height) | 120*200*80 | 200*300*120 | 250*400*160 | 300*500*200 | 120*200*80 | 200*300*120 | 250*400*160 | 300*500*200 |
| Rated temperature | 1000°C | 1200°C | ||||||
