Features of Medical Refrigerator:
- Applications
Applicable to pharmacies, pharmaceutical factories, hospitals, clinics, scientific research institutes, disease prevention and control centers and other industry institutions;
Used to store medicines, reagents, vaccines, biological products, etc.
- Temperature control
Microcomputer digital control, real-time display of temperature and humidity, display accuracy 0.1°C:
The temperature in the box is controlled within the range of 2~8°C;
Configure temperature and humidity display, record, and data upload functions according to requirements to meet GSP requirements.
- Security system
Multiple fault alarms: high and low temperature alarm, power failure alarm, door opening alarm, sensor failure alarm;
Multiple alarm methods: sound buzzer alarm, light flashing alarm.
- Cooling system
Adopt well-known brand compressor, stable and reliable performance, long service life;
Using German EBM silent fan, stable and durable performance, low noise;
Unique fluorine-free environmentally friendly refrigerant.
- Humanized design
Easy access: shelves with label strips for user identification to store medicines;
High safety: the door is equipped with a safety door lock, and the inner tank is made of 304 stainless steel;
Energy saving: Built-in lighting, high brightness and energy saving, the reagents in the cabinet are clear at a glance;
Strong applicability: 187V~242V wide voltage design, suitable for environments with unstable voltage.
Specification of Medical Refrigerator:
Product number | External dimensions (mm W*D*H) | Internal dimensions (mm W*D*H) | Temperature (°C) | Power (W) | Net weight (kg) | Volume (L) |
TYC-L70 | 450*550*860 | 370*460*640 | 2~8 | 170 | 39 | 70 |
TYC-L130 | 522*595*1365 | 432*500*843 | 2~8 | 240 | 62 | 130 |
TYC-L230 | 595*605*1620 | 515*510*1085 | 2~8 | 280 | 73 | 230 |
TYC-L300 | 595*605*1940 | 515*510*1405 | 2~8 | 300 | 83 | 300 |
TYC-1360 | 680*650*1975 | 580*550*1520 | 2~8 | 320 | 105 | 360 |
TYC-L400 | 680*745*1870 | 560*610*1380 | 2~8 | 430 | 115 | 400 |
TYC-L560 | 1200*650*1890 | 1112*560*1230 | 2~8 | 490 | 131 | 560 |
TYC-L660 | 1100*685*2080 | 985*565*1595 | 2~8 | 550 | 175 | 660 |
TYC-L760 | 1200*745*1870 | 1080*610*1380 | 2~8 | 580 | 158 | 760 |
TYC-L1160 | 1800*745*1870 | 1680*610*1380 | 2~8 | 650 | 171 | 1160 |
TYC-L1360 | 1880*745*2070 | 1790*590*1570 | 2~8 | 720 | 195 | 1360 |
